StreamState Class Reference

#include <OnDemandServerMediaSubsession.hh>

Collaboration diagram for StreamState:

Collaboration graph
[legend]

Public Member Functions

 StreamState (OnDemandServerMediaSubsession &master, Port const &serverRTPPort, Port const &serverRTCPPort, RTPSink *rtpSink, BasicUDPSink *udpSink, unsigned totalBW, FramedSource *mediaSource, Groupsock *rtpGS, Groupsock *rtcpGS)
virtual ~StreamState ()
void startPlaying (Destinations *destinations, TaskFunc *rtcpRRHandler, void *rtcpRRHandlerClientData, ServerRequestAlternativeByteHandler *serverRequestAlternativeByteHandler, void *serverRequestAlternativeByteHandlerClientData)
void pause ()
void endPlaying (Destinations *destinations)
void reclaim ()
unsigned & referenceCount ()
Port const & serverRTPPort () const
Port const & serverRTCPPort () const
RTPSink * rtpSink () const
float streamDuration () const
FramedSource * mediaSource () const
float & startNPT ()

Private Attributes

OnDemandServerMediaSubsession & fMaster
Boolean fAreCurrentlyPlaying
unsigned fReferenceCount
Port fServerRTPPort
Port fServerRTCPPort
RTPSink * fRTPSink
BasicUDPSink * fUDPSink
float fStreamDuration
unsigned fTotalBW
RTCPInstance * fRTCPInstance
FramedSource * fMediaSource
float fStartNPT
Groupsock * fRTPgs
Groupsock * fRTCPgs

Detailed Description

Definition at line 141 of file OnDemandServerMediaSubsession.hh.

Constructor & Destructor Documentation

StreamState::StreamState ( OnDemandServerMediaSubsession &  master,
Port const &  serverRTPPort,
Port const &  serverRTCPPort,
RTPSink *  rtpSink,
BasicUDPSink *  udpSink,
unsigned  totalBW,
FramedSource *  mediaSource,
Groupsock *  rtpGS,
Groupsock *  rtcpGS
)

Definition at line 409 of file OnDemandServerMediaSubsession.cpp.

00414   : fMaster(master), fAreCurrentlyPlaying(False), fReferenceCount(1),
00415     fServerRTPPort(serverRTPPort), fServerRTCPPort(serverRTCPPort),
00416     fRTPSink(rtpSink), fUDPSink(udpSink), fStreamDuration(master.duration()),
00417     fTotalBW(totalBW), fRTCPInstance(NULL) /* created later */,
00418     fMediaSource(mediaSource), fStartNPT(0.0), fRTPgs(rtpGS), fRTCPgs(rtcpGS) {
00419 }

StreamState::~StreamState (  )  [virtual]

Definition at line 421 of file OnDemandServerMediaSubsession.cpp.

References reclaim().

00421                           {
00422   reclaim();
00423 }

Member Function Documentation

void StreamState::startPlaying ( Destinations *  destinations,
TaskFunc *  rtcpRRHandler,
void *  rtcpRRHandlerClientData,
ServerRequestAlternativeByteHandler *  serverRequestAlternativeByteHandler,
void *  serverRequestAlternativeByteHandlerClientData
)

Definition at line 426 of file OnDemandServerMediaSubsession.cpp.

References Groupsock::addDestination(), Destinations::addr, RTCPInstance::addStreamSocket(), RTPSink::addStreamSocket(), afterPlayingStreamState(), RTCPInstance::createNew(), Medium::envir(), fAreCurrentlyPlaying, OnDemandServerMediaSubsession::fCNAME, fMaster, fMediaSource, fRTCPgs, fRTCPInstance, fRTPgs, fRTPSink, fTotalBW, fUDPSink, Destinations::isTCP, NULL, Destinations::rtcpChannelId, Destinations::rtcpPort, Destinations::rtpChannelId, Destinations::rtpPort, RTCPInstance::sendReport(), RTPSink::setServerRequestAlternativeByteHandler(), RTCPInstance::setSpecificRRHandler(), MediaSink::startPlaying(), Destinations::tcpSocketNum, and True.

Referenced by OnDemandServerMediaSubsession::startStream().

00429                                                                     {
00430   if (dests == NULL) return;
00431
00432   if (fRTCPInstance == NULL && fRTPSink != NULL) {
00433     // Create (and start) a 'RTCP instance' for this RTP sink:
00434     fRTCPInstance
00435       = RTCPInstance::createNew(fRTPSink->envir(), fRTCPgs,
00436                                 fTotalBW, (unsigned char*)fMaster.fCNAME,
00437                                 fRTPSink, NULL /* we're a server */);
00438         // Note: This starts RTCP running automatically
00439   }
00440
00441   if (dests->isTCP) {
00442     // Change RTP and RTCP to use the TCP socket instead of UDP:
00443     if (fRTPSink != NULL) {
00444       fRTPSink->addStreamSocket(dests->tcpSocketNum, dests->rtpChannelId);
00445       fRTPSink->setServerRequestAlternativeByteHandler(dests->tcpSocketNum, serverRequestAlternativeByteHandler, serverRequestAlternativeByteHandlerClientData);
00446     }
00447     if (fRTCPInstance != NULL) {
00448       fRTCPInstance->addStreamSocket(dests->tcpSocketNum, dests->rtcpChannelId);
00449       fRTCPInstance->setSpecificRRHandler(dests->tcpSocketNum, dests->rtcpChannelId,
00450                                           rtcpRRHandler, rtcpRRHandlerClientData);
00451     }
00452   } else {
00453     // Tell the RTP and RTCP 'groupsocks' about this destination
00454     // (in case they don't already have it):
00455     if (fRTPgs != NULL) fRTPgs->addDestination(dests->addr, dests->rtpPort);
00456     if (fRTCPgs != NULL) fRTCPgs->addDestination(dests->addr, dests->rtcpPort);
00457     if (fRTCPInstance != NULL) {
00458       fRTCPInstance->setSpecificRRHandler(dests->addr.s_addr, dests->rtcpPort,
00459                                           rtcpRRHandler, rtcpRRHandlerClientData);
00460     }
00461   }
00462
00463   if (fRTCPInstance != NULL) {
00464     // Hack: Send an initial RTCP "SR" packet, before the initial RTP packet, so that receivers will (likely) be able to
00465     // get RTCP-synchronized presentation times immediately:
00466     fRTCPInstance->sendReport();
00467   }
00468
00469   if (!fAreCurrentlyPlaying && fMediaSource != NULL) {
00470     if (fRTPSink != NULL) {
00471       fRTPSink->startPlaying(*fMediaSource, afterPlayingStreamState, this);
00472       fAreCurrentlyPlaying = True;
00473     } else if (fUDPSink != NULL) {
00474       fUDPSink->startPlaying(*fMediaSource, afterPlayingStreamState, this);
00475       fAreCurrentlyPlaying = True;
00476     }
00477   }
00478 }

void StreamState::pause (  )

Definition at line 480 of file OnDemandServerMediaSubsession.cpp.

References False, fAreCurrentlyPlaying, fRTPSink, fUDPSink, NULL, and MediaSink::stopPlaying().

Referenced by OnDemandServerMediaSubsession::pauseStream().

00480                         {
00481   if (fRTPSink != NULL) fRTPSink->stopPlaying();
00482   if (fUDPSink != NULL) fUDPSink->stopPlaying();
00483   fAreCurrentlyPlaying = False;
00484 }

void StreamState::endPlaying ( Destinations *  destinations  )

Definition at line 486 of file OnDemandServerMediaSubsession.cpp.

References Destinations::addr, fRTCPgs, fRTCPInstance, fRTPgs, fRTPSink, Destinations::isTCP, NULL, Groupsock::removeDestination(), RTCPInstance::removeStreamSocket(), RTPSink::removeStreamSocket(), Destinations::rtcpChannelId, Destinations::rtcpPort, Destinations::rtpChannelId, Destinations::rtpPort, RTCPInstance::sendBYE(), Destinations::tcpSocketNum, and RTCPInstance::unsetSpecificRRHandler().

Referenced by OnDemandServerMediaSubsession::deleteStream().

00486                                                 {
00487 #if 0
00488   // The following code is temporarily disabled, because it erroneously sends RTCP "BYE"s to all clients if multiple
00489   // clients are streaming from the samedata source (i.e., if "reuseFirstSource" is True).  It will be fixed for real later.
00490   if (fRTCPInstance != NULL) {
00491     // Hack: Explicitly send a RTCP "BYE" packet now, because the code below will prevent that from happening later,
00492     // when "fRTCPInstance" gets deleted:
00493     fRTCPInstance->sendBYE();
00494   }
00495 #endif
00496
00497   if (dests->isTCP) {
00498     if (fRTPSink != NULL) {
00499       fRTPSink->removeStreamSocket(dests->tcpSocketNum, dests->rtpChannelId);
00500     }
00501     if (fRTCPInstance != NULL) {
00502       fRTCPInstance->removeStreamSocket(dests->tcpSocketNum, dests->rtcpChannelId);
00503       fRTCPInstance->unsetSpecificRRHandler(dests->tcpSocketNum, dests->rtcpChannelId);
00504     }
00505   } else {
00506     // Tell the RTP and RTCP 'groupsocks' to stop using these destinations:
00507     if (fRTPgs != NULL) fRTPgs->removeDestination(dests->addr, dests->rtpPort);
00508     if (fRTCPgs != NULL) fRTCPgs->removeDestination(dests->addr, dests->rtcpPort);
00509     if (fRTCPInstance != NULL) {
00510       fRTCPInstance->unsetSpecificRRHandler(dests->addr.s_addr, dests->rtcpPort);
00511     }
00512   }
00513 }

void StreamState::reclaim (  )

Definition at line 515 of file OnDemandServerMediaSubsession.cpp.

References Medium::close(), OnDemandServerMediaSubsession::closeStreamSource(), OnDemandServerMediaSubsession::fLastStreamToken, fMaster, fMediaSource, fRTCPgs, fRTCPInstance, fRTPgs, fRTPSink, fUDPSink, and NULL.

Referenced by afterPlayingStreamState(), and ~StreamState().

00515                           {
00516   // Delete allocated media objects
00517   Medium::close(fRTCPInstance) /* will send a RTCP BYE */; fRTCPInstance = NULL;
00518   Medium::close(fRTPSink); fRTPSink = NULL;
00519   Medium::close(fUDPSink); fUDPSink = NULL;
00520
00521   fMaster.closeStreamSource(fMediaSource); fMediaSource = NULL;
00522   if (fMaster.fLastStreamToken == this) fMaster.fLastStreamToken = NULL;
00523
00524   delete fRTPgs; fRTPgs = NULL;
00525   delete fRTCPgs; fRTCPgs = NULL;
00526 }

unsigned& StreamState::referenceCount (  )  [inline]

Definition at line 158 of file OnDemandServerMediaSubsession.hh.

References fReferenceCount.

Referenced by OnDemandServerMediaSubsession::deleteStream().

00158 { return fReferenceCount; }

Port const& StreamState::serverRTPPort (  )  const [inline]

Definition at line 160 of file OnDemandServerMediaSubsession.hh.

References fServerRTPPort.

00160 { return fServerRTPPort; }

Port const& StreamState::serverRTCPPort (  )  const [inline]

Definition at line 161 of file OnDemandServerMediaSubsession.hh.

References fServerRTCPPort.

00161 { return fServerRTCPPort; }

RTPSink* StreamState::rtpSink (  )  const [inline]

Definition at line 163 of file OnDemandServerMediaSubsession.hh.

References fRTPSink.

Referenced by OnDemandServerMediaSubsession::getCurrentNPT(), OnDemandServerMediaSubsession::nullSeekStream(), OnDemandServerMediaSubsession::seekStream(), and OnDemandServerMediaSubsession::startStream().

00163 { return fRTPSink; }

float StreamState::streamDuration (  )  const [inline]

Definition at line 165 of file OnDemandServerMediaSubsession.hh.

References fStreamDuration.

Referenced by afterPlayingStreamState().

00165 { return fStreamDuration; }

FramedSource* StreamState::mediaSource (  )  const [inline]

Definition at line 167 of file OnDemandServerMediaSubsession.hh.

References fMediaSource.

Referenced by OnDemandServerMediaSubsession::getStreamSource(), OnDemandServerMediaSubsession::nullSeekStream(), OnDemandServerMediaSubsession::seekStream(), and OnDemandServerMediaSubsession::setStreamScale().

00167 { return fMediaSource; }

float& StreamState::startNPT (  )  [inline]

Definition at line 168 of file OnDemandServerMediaSubsession.hh.

References fStartNPT.

Referenced by OnDemandServerMediaSubsession::getCurrentNPT(), OnDemandServerMediaSubsession::nullSeekStream(), and OnDemandServerMediaSubsession::seekStream().

00168 { return fStartNPT; }

Field Documentation

OnDemandServerMediaSubsession& StreamState::fMaster [private]

Definition at line 171 of file OnDemandServerMediaSubsession.hh.

Referenced by reclaim(), and startPlaying().

Boolean StreamState::fAreCurrentlyPlaying [private]

Definition at line 172 of file OnDemandServerMediaSubsession.hh.

Referenced by pause(), and startPlaying().

unsigned StreamState::fReferenceCount [private]

Definition at line 173 of file OnDemandServerMediaSubsession.hh.

Referenced by referenceCount().

Port StreamState::fServerRTPPort [private]

Definition at line 175 of file OnDemandServerMediaSubsession.hh.

Referenced by serverRTPPort().

Port StreamState::fServerRTCPPort [private]

Definition at line 175 of file OnDemandServerMediaSubsession.hh.

Referenced by serverRTCPPort().

RTPSink* StreamState::fRTPSink [private]

Definition at line 177 of file OnDemandServerMediaSubsession.hh.

Referenced by endPlaying(), pause(), reclaim(), rtpSink(), and startPlaying().

BasicUDPSink* StreamState::fUDPSink [private]

Definition at line 178 of file OnDemandServerMediaSubsession.hh.

Referenced by pause(), reclaim(), and startPlaying().

float StreamState::fStreamDuration [private]

Definition at line 180 of file OnDemandServerMediaSubsession.hh.

Referenced by streamDuration().

unsigned StreamState::fTotalBW [private]

Definition at line 181 of file OnDemandServerMediaSubsession.hh.

Referenced by startPlaying().

RTCPInstance* StreamState::fRTCPInstance [private]

Definition at line 182 of file OnDemandServerMediaSubsession.hh.

Referenced by endPlaying(), reclaim(), and startPlaying().

FramedSource* StreamState::fMediaSource [private]

Definition at line 184 of file OnDemandServerMediaSubsession.hh.

Referenced by mediaSource(), reclaim(), and startPlaying().

float StreamState::fStartNPT [private]

Definition at line 185 of file OnDemandServerMediaSubsession.hh.

Referenced by startNPT().

Groupsock* StreamState::fRTPgs [private]

Definition at line 187 of file OnDemandServerMediaSubsession.hh.

Referenced by endPlaying(), reclaim(), and startPlaying().

Groupsock* StreamState::fRTCPgs [private]

Definition at line 188 of file OnDemandServerMediaSubsession.hh.

Referenced by endPlaying(), reclaim(), and startPlaying().

The documentation for this class was generated from the following files:
